Overview

The Ball and Beam module consists of a steel rod in parallel with a nickel-chromium, wire-wound resistor forming the track on which the metal ball is free to roll. The track is effectively a potentiometer, outputting a voltage that’s proportional to the position of the ball.

When coupled to the Rotary Servo Base Unit, the tilt angle of the beam can be controlled by changing the servo gear angle. The Ball and Beam module can be operated in stand-alone mode, and the ball position can be controlled via the user interface. The Ball and Beam module can also be paired with an additional Remote Sensor module, in which case the system operates in a Master/Slave mode where the ball on the beam will follow the reference ball position of the second Ball and Beam module.

  • High-quality aluminum chassis with precision-crafted parts
  • Robust machined aluminum casing with stainless steel rod
  • Ball and Beam module easily attaches to Rotary Servo Base Unit
  • Optional Master/Slave configuration with additional Ball and Beam module
  • Easy-connect cables and connectors
Modeling Topics
  • First-principles derivation
  • Transfer function representation
  • Linearization
  • Model validation
Control Topics
  • Multiple loops
  • PID

The following additional components are required to complete your workstation, and are sold separately:

For Simulink

  • QUARC® add-on for MATLAB®/Simulink®
  • One Rotary Servo Base Unit
  • Quanser VoltPAQ-X1 linear voltage amplifier
  • One of the following DAQ devices:
    • Quanser Q2-USB
    • Quanser Q8-USB
    • Quanser QPIDe

For LabVIEW

  • Quanser Rapid Control Prototyping (Q-RCP) Toolkit® add-on for NI LabVIEW™
  • One Rotary Servo Base Unit
  • Quanser VoltPAQ-X1 linear voltage amplifier
  • One of the following DAQ devices:
    • NI CompactRIO with Quanser Q1-cRIO
    • NI myRIO with Quanser Terminal Board
    • Quanser Q2-USB
    • Quanser Q8-USB
    • Quanser QPIDe

Product Details

Calibrationed base dimensions (L x W) 50 cm  x 22.5 cm
Beam length 42.55 cm
Lever arm length 12 cm
Support arm length 16 cm
Ball diameter 2.54 cm
Ball mass 0.064 kg
Ball position sensor bias power ±12 V
Ball position sensor measurement range ±5 V
Ball and Beam module mass 0.65 kg
